Dbx 223XL Crossover
Original price was: KSh 12,000.KSh 10,500Current price is: KSh 10,500.
- High-Quality Construction: Built with precision controls that offer a solid “click” feel, the dbx 223XL ensures reliability and durability, even in demanding environments.
- Integrated Power Supply: Unlike many processors in its price range, the dbx 223XL features an internal power supply, eliminating the hassle of managing an external unit while ensuring consistent performance.
- Robust Connectivity: All inputs and outputs utilize balanced XLR connectors securely attached to the chassis, providing added durability and minimizing the risk of damage from cable stress.
- Versatile Operation Modes: Easily switch between stereo 2-way and mono 3-way operation modes, allowing flexibility for various audio setups and applications.
- Effective Low Frequency Management: The low frequency summed output is designed for subwoofer applications, optimizing amplifier power and providing better control over low-end frequencies.
- Adjustable Crossover Frequencies: The crossover frequency range can be adjusted for each channel individually, enabling precise tuning to match specific speaker and environment requirements.
- Phase Reverse Capability: Each output features a phase reverse switch, allowing quick adjustments to address phase issues without needing to reconfigure the entire system.
- Professional Sound Quality: Utilizing Linkwitz-Riley 24 dB per octave filters, the dbx 223XL meets professional standards for audio clarity and separation, ensuring an optimal listening experience across all sound frequencies.
Order on WhatsApp
Description
The dbx 223XL Stereo 2-Way/Mono 3-Way Crossover is a professional-grade audio processor designed for high-performance sound systems. Featuring robust XLR balanced connections, this crossover offers flexible operation modes and precise control over crossover frequencies with its Linkwitz-Riley 24dB per octave filters.
The compact design integrates a high-quality internal power supply, ensuring reliability and ease of use. With features like phase invert switches, low cut filters, and individual level controls, the dbx 223XL is perfect for both portable and fixed installations, delivering exceptional audio clarity and performance.
Dbx 223XL Specifications
| Specs | Details | |
| Inputs | Input Connectors | XLR (pin 2 hot) |
| Input Type | Electronically balanced/unbalanced, RF filtered | |
| Input Impedance | Balanced: >50k ohm, Unbalanced: >25k ohm | |
| Max Input | >+22 dBu balanced or unbalanced | |
| Common Mode Rejection Ratio (CMRR) | >40 dB, typically >55 dB at 1 kHz | |
| Outputs | Output Connectors | XLR |
| Output Type | Impedance-balanced/unbalanced, RF filtered | |
| Output Impedance | Balanced: 200 ohm, Unbalanced: 100 ohm | |
| Max Output | >+22 dBu balanced/unbalanced into 2k or greater | |
| Performance | Bandwidth | 20 Hz to 20 kHz, +/-0.5 dB |
| Frequency Response | < 3 Hz to > 90 kHz, +0/-3 dB | |
| Signal to Noise Ratio | Ref: +4 dBu, 22 kHz measurement bandwidth | |
| Signal-to-Noise (Stereo Mode) | >94 dB (Low Output), >92 dB (High Output) | |
| Signal-to-Noise (Mono Mode) | >94 dB (Low Output), >93 dB (Mid Output), >92 dB (High Output) | |
| Dynamic Range | > 114 dB, unweighted, any output | |
| THD+Noise | < 0.004% at +4 dBu, 1 kHz; < 0.04% at +20 dBu, 1 kHz | |
| Interchannel Crosstalk | < -80 dB, 20 Hz to 20 kHz | |
| Crossover | Crossover Frequencies (Stereo Mode) | Low/High: 45 to 960 Hz or 450 Hz to 9.6 kHz (x10 setting) |
| Crossover Frequencies (Mono Mode) | Low/Mid: 45 to 960 Hz or 450 Hz to 9.6 kHz (x10 setting); Mid/High: 45 to 960 Hz or 450 Hz to 9.6 kHz (x10 setting) | |
| Crossover Filter Type | Linkwitz-Riley, 24 dB/octave, state-variable | |
| Controls | Low Cut Switch | Activates 40 Hz Butterworth, 12 dB/octave high-pass filter, one switch per channel |
| Phase Invert Switch | Inverts the phase at the output, one switch per output | |
| x1 / x10 Switch | Multiplies the low-high (mono: low/mid and high/mid) crossover frequency range by a factor of 1 or 10, one switch per channel | |
| Mode Switch | Selects stereo 2-way or mono 3-way operation | |
| LF Sum Switch | Selects normal (stereo) or mono-summed low frequency operation | |
| Indicators | Indicators | Stereo Operation (Green); Mono Operation (Yellow); Low Cut (Red-per channel); x10 (Green-per channel); Phase Invert (Red-per output) |
| Power | Operating Voltage | 100 VAC 50/60 Hz; 120 VAC 60 Hz; 230 VAC 50 Hz |
| Power Consumption | 15W | |
| Power Connector | IEC receptacle | |
| Physical | Dimensions | 1.75″ H x 19″ W x 6.9″ D (4.4 cm x 48.3 cm x 17.5 cm) |
| Unit Weight | 3.7 lbs. (1.7 kg) | |
| Shipping Weight | 5.4 lbs. (2.5 kg) |
